Double Layer PE Stretch/Cling Film Machine

Double Layer PE Stretch/Cling Film Machine

65*85
Application:
Used in making single layer or double layers stretch film and cling film with single face or double face stickiness.

Consult

Features Technical Indicators Overall Dimension

(1)This machine employed two extruders with double layers distributor and double T-die,which can make single layer,double layers stretch film or food package film with single face stickness or double face stickness.
(2) Auto vacuum load,on-line recycling device,auto count,auto cutting and auto change winding roll,controlled by PLC.

Main Technical Parameters
Model	HWLS-(Φ55+Φ65)×1250	HWLS-(Φ55+Φ80)x1750
Material of screw&barrel	38CrMoAIA+nitriding	38CrMoAlA+nitriding
Diameter of screw(mm)	Φ55+Φ65	Φ65+Φ80
Screw L/D	32:1	32:1
Screw rotary speed(rpm)	20-150	20-150
Die width(mm)	1250	1750
Power of main motor(kw)	15+30	15+37
Total power(kw)	78	90
Film thicknesss(mm)	0.009-0.05	0.009-0.05
Width of products(mm)	500x2/1000	500x3/1000
Capacity(kg/h)	50-120	100-180
Weight(kg)	6500	7500
Dimension(mm)	4800x2000×3200	6000x3800x3500
